High Speed Full Automatic Paper Rigid Box Making Machine For Gift Box , Jewellery Box
characteristics:
using visual robot positioning, positioning accuracy ± 0.1mm;
It is more stable with servo feeder feeding.
Debugging is quick and easy to operate.
Automatic Paper Box Making Machine Description:
The Automatic Paper Box Making Machine adopts motion controller, visual manipulator for positioning ,HMI System,which make it possible that paper feeding, gluing, cardboard four corners taping, feeding, edge covering, full ear folding, forming and shaping of the finished box are completed in one operation.Through the electronic cam gear rack structure driving the box mold to operate, it can independently complete multiple deep folding operations so as to meet the requirements of high-end products and boxes free of folding trace in the market.
Automatic Paper Box Making Machine Parameters:
| Model | ZY-450 |
| Max. size of box | 450x450x120mm |
| Min. size of box | 45x45x8mm |
| Folding-in Depth | 8-120mm |
| Power consumption | 2.0KW |
| Speed | 0-35pcs/min |
| Voltage | AC220V |
| Air consumption | 8L/min 0.65Mpa |
| Weight | 1500kg |
| Measurement: | 7500x1200x1150mm |
Quick details:
1. The equipment is fully automatic, realizing automatic paper feeding, gluing, cardboard flattening, positioning automatic paper picking, box sticking, edge sealing and forming, which greatly improves work efficiency.
2. It can still be glued properly in harsh environments.
3. Paste and position accurately, make the box look more beautiful, so it presents the unique value of the exquisite box.
4. The fully automatic system allows the carton to be quickly transferred, making the paper difficult to fold, curl and deform, thus completing the boxing process with ease and perfection.
Application range:
Mobile phone case, underwear box, gift box, food box, plastic box
This machine is designed for packaging boxes, such as jewellery box, gift box, mobile box, tea box,etc.
All of the relevant products are internationally high-end products, low breakdown, high accuracy.
Our service:
Quickly reply to your inquiry
Experienced staff will answer all your questions in a timely manner.
Our highly trained staff can provide customers with exclusive and unique solutions.
As an honest seller, we always provide advanced machines to ensure that our products have high quality and stable functions.
Primary products:
Automatic Rigid Box Making Machine
Automatic Paper Box Making Machine
Jewellery Box Making Machine
Box Forming Machine
Box Assembly Machine
Corner Pasting Machine
Paper Gluing Machine
Automatic Grooving Machine
Etc.
